To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | VCC |
| Manufacturer Product Number | CMD95-21VYC/TR7 |
| Description | Surface Mount LED; Yellow; 2.1x2.2mm gull wing; 585 nm; 25 mcd; 25°; Water Clear |
| Datasheet | Download Datasheet |
The VCC CMD95-21VYC/TR7 is a yellow surface mount LED in a 2.1x2.2mm gull wing package, with a peak wavelength of 585 nm.
It is rated 25 mcd typical (16 mcd minimum), with a forward voltage of 2 V (2.8 V maximum).
Its water clear lens gives a 25° viewing angle.
It operates from -40°C to +85°C.
| Category | |
| Manufacturer | VCC |
| Color | Yellow |
| Configuration | Single Color |
| Peak Wavelength (nm) | 585 |
| Luminous Intensity (mcd) | 25 |
| Luminous Intensity (Min) (mcd) | 16 |
| Forward Voltage (V) | 2 |
| Forward Voltage (Max) (V) | 2.8 |
| Viewing Angle (°) | 25 |
| Lens | Water Clear |
| Package Size | 2.1x2.2mm gull wing (TR7) |
| Mounting Type | Surface Mount |
| Lens Style | Round with Domed Top |
| Lens Size | 1.80mm Dia |
| Height (Max) (mm) | 2.78 |
| Forward Current (Max) (mA) | 30 |
| Power Dissipation (mW) | 105 |
| Operating Temperature (°C) | -40°C ~ +85°C |
