To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | TimeMark |
| Manufacturer Product Number | 2681-24VDC |
| Description | Voltage Monitor Relay; Voltage Band (over and under); 24V DC; 0.5 s ±0.1 s (fixed) |
| Datasheet | Download Datasheet |
The TimeMark 2681-24VDC is a voltage band monitor for 24 V DC systems. Its relay stays energized while the voltage is inside the band and drops out when it goes above or below it.
Trip points: low voltage 19-24 V DC (adjustable); high voltage 24-29 V DC (adjustable). Trip delay: 0.5 s ±0.1 s (fixed). Reset: automatic.
Output: 1C SPDT, 10 A at 240 V AC resistive. Mounting: plug-in. It operates from -7 to +50 °C.
| Category | |
| Manufacturer | TimeMark |
| Model | 2681 |
| Monitoring Function | Voltage Band (over and under) |
| Input Voltage | 24V DC |
| Maximum Voltage | 32V DC |
| Low Voltage Trip / Reset | 19...24V DC (adjustable) |
| High Voltage Trip / Reset | 24...29V DC (adjustable) |
| Trip Delay | 0.5 s ±0.1 s (fixed) |
| Reset Method | Automatic |
| Contact Configuration | 1C SPDT |
| Number of Poles | 1 |
| Output Rating | 10 A at 240 V AC resistive |
| Mounting Type | Socketable |
| Termination Style | Plug In, 8 Pin (Octal) |
| Dimensions | 3.52" overall length (2.88" body) x 1.75" x 2.44" (tolerance ± 0.06) |
| Operating Temperature (Storage) (°C) | -7...+50 |
