To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | TimeMark |
| Manufacturer Product Number | 368-L-1MIN/SG |
| Description | TDR; 1...1,023 min; Recycle (Off First); 10-28 V AC/DC |
| Datasheet | Download Datasheet |
The TimeMark 368-L-1MIN/SG is a recycling (OFF first) time delay relay for 10-28 V AC/DC, with DPDT contacts rated 10 A resistive at 240 V AC. Its timing is adjustable from 1 to 1,023 minutes with binary-weighted DIP switches. Timing starts when input voltage is applied.
Contact rating: 10 A resistive at 240 V AC; 4 A general use at 120 V AC. Pilot duty: C300 (120 V: make 15 A, break 1.5 A; 240 V: make 7.5 A, break 0.75 A). Silver contacts with gold flash (/SG). Indicator: LED (green / red). Repeat accuracy: +-0.1%. Setting accuracy: +-2%. Power: 3 W max.
It plugs into an 8-pin octal socket (TimeMark 51X120, sold separately). It operates from -29 to +60 °C. Approvals: UL Recognized, CSA Certified.
| Category | |
| Manufacturer | TimeMark |
| Model | 368 |
| Output Technology | Electromechanical Relay |
| Timing Function | Recycle (Off First) |
| Delay Time | 1...1,023 min |
| Timing Adjustment Method | DIP switches (binary 1-512) |
| Options | Silver contacts with gold flash (/SG) |
| Timing Initiate Method | Input voltage |
| Status Indicator | LED (green / red) |
| Contact Configuration | 2C DPDT |
| Output Rating | 10 A resistive at 240 V AC; 4 A general use at 120 V AC |
| Pilot Duty | C300 (120 V: make 15 A, break 1.5 A; 240 V: make 7.5 A, break 0.75 A) |
| Input Voltage | 10-28 V AC/DC |
| Termination Style | Plug In, 8 Pin (Octal) |
| Mounting Type | Socketable |
| Socket Family | 8 Pin Octal |
| Required Socket | TimeMark 51X120 (8-pin, not included) |
| Operating Temperature (°C) | -29...+60 |
| Approvals | UL Recognized, CSA Certified |
| Setting Accuracy (%) | +-2% |
| Repeatability (%) | +-0.1% |
| Rated Power | 3 W max |
