To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | TimeMark |
| Manufacturer Product Number | 208D-208/240V |
| Description | Phase Sequence Detector; 208/240V AC; 400 Hz |
| Datasheet | Download Datasheet |
The TimeMark 208D-208/240V is a wall-plate line voltage and phase sequence indicator. It shows phase sequence (ABC / CBA), voltage on each phase and which phase is missing.
Line voltage: 208/240V AC. Frequency: 400 Hz. Phases: 3-phase, wye or delta. Indication: 5 lamps: ØA, ØB, ØC line voltage; CBA, ABC rotation. Leads: fly leads (22 ga/600V). Power: line powered. Connection time: continuous. Body: ABS plastic.
Mounting: wall plate (fly leads). Dimensions: 4.55" x 2.94" plate; 2.0" body depth; .31" plate.
| Category | |
| Manufacturer | TimeMark |
| Model | 208D |
| Part Status | Discontinued |
| Device Type | Wall-plate indicator (wall switch box) |
| Function | Shows phase sequence (ABC / CBA), voltage on each phase and which phase is missing |
| Line Voltage | 208/240V AC |
| Frequency | 400 Hz |
| Number of Phases | 3-phase, wye or delta |
| Indication | 5 lamps: ØA, ØB, ØC line voltage; CBA, ABC rotation |
| Connection | Fly leads (22 ga/600V) |
| Power Source | Line powered |
| Connection Time | Continuous |
| Mounting Type | Wall plate (fly leads) |
| Dimensions | 4.55" x 2.94" plate; 2.0" body depth; .31" plate |
| Housing Material | ABS plastic |
