To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | SunLED |
| Manufacturer Product Number | XSVG43MB |
| Description | Through Hole LED; Green; 3x3mm Square; 574 nm; 19 mcd; 140°; White Triple |
| Datasheet | Download Datasheet |
The SunLED XSVG43MB is a green through hole LED in a 3x3mm Square package, with a peak wavelength of 574 nm.
It is rated 19 mcd typical (12 mcd minimum) at 20 mA, with a forward voltage of 2.1 V (2.5 V maximum).
Its white triple lens gives a 140° viewing angle.
It operates from -40°C to +85°C.
| Category | |
| Manufacturer | SunLED |
| Color | Green |
| Configuration | Single Color |
| Peak Wavelength (nm) | 574 |
| Dominant Wavelength (nm) | 570 |
| Luminous Intensity (mcd) | 19 |
| Luminous Intensity (Min) (mcd) | 12 |
| Test Current (mA) | 20 |
| Forward Voltage (V) | 2.1 |
| Forward Voltage (Max) (V) | 2.5 |
| Viewing Angle (°) | 140 |
| Lens | White Triple |
| Package Size | 3x3mm Square (Ice Cube LED) |
| Mounting Type | Through Hole |
| Lens Style | Square with Flat Top |
| Lens Size | 3.00mm |
| Height (Max) (mm) | 4.8 |
| Emitting Material | AlGaInP |
| Forward Current (Max) (mA) | 30 |
| Power Dissipation (mW) | 75 |
| Operating Temperature (°C) | -40°C ~ +85°C |
