To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | SunLED |
| Manufacturer Product Number | XLUGY37M |
| Description | Through Hole LED; Green / Yellow; 3mm Round; 565 / 590 nm; 13 / 7 mcd; 60° |
| Datasheet | Download Datasheet |
The SunLED XLUGY37M is a bi-color green / yellow through hole LED in a 3mm Round package, with a peak wavelength of 565 nm green and 590 nm yellow.
It is rated 13 mcd green and 7 mcd yellow typical (6 mcd green and 4 mcd yellow minimum) at 20 mA, with a forward voltage of 2.2 V green and 2.1 V yellow.
Its white diffused lens gives a 60° viewing angle.
It operates from -40°C to +85°C.
| Category | |
| Manufacturer | SunLED |
| Color | Green / Yellow |
| Configuration | Bi-Color |
| Peak Wavelength (nm) | 565 / 590 |
| Dominant Wavelength (nm) | 568 / 588 |
| Luminous Intensity (mcd) | 13 / 7 |
| Luminous Intensity (Min) (mcd) | 6 / 4 |
| Test Current (mA) | 20 |
| Forward Voltage (V) | 2.2 / 2.1 |
| Forward Voltage (Max) (V) | 2.5 / 2.5 |
| Viewing Angle (°) | 60 |
| Lens | White Diffused |
| Package Size | 3mm Round (Bi-Polar) |
| Mounting Type | Through Hole |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
| Height (Max) (mm) | 4.6 |
| Emitting Material | GaP / GaAsP/GaP |
| Forward Current (Max) (mA) | 25 / 30 |
| Power Dissipation (mW) | 62.5 / 75 |
| Operating Temperature (°C) | -40°C ~ +85°C |
