Product Description
Description: Reed Relay • Mounting: Through Hole (THT) • Contact Form: 1A SPST-NO • Coil Voltage: 12 VDC • Switching Voltage: < 200 VDC • Switching Current (max.): - • Option: Standard • Special Feature: Low Consumption Coil
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting | Through Hole (THT) |
| Contact Form | 1A SPST-NO |
| Coil Voltage | 12 VDC |
| Switching Voltage | < 200 VDC |
| Switching Current (max.) | - |
| Option | Standard |
| Special Feature | Low Consumption Coil |
| Coil Resistance (typ.) | 1800 |
| Pull-In Voltage (VDC) | 8.4 |
| Drop-Out Voltage (VDC) | 1.8 |
| Nominal Coil Power (typ.) mw | 80 |
| Series Features |
| DIL Series Reed Relay |
| Series Description: General purpose line sensing dual in-line DIL Series Reed Relay with coil up to 11.000 ?. Supplied in an epoxy encapsulated package. Available with dielectric strength 4.25kVDC. Optional diode and magnetic shield. UL approval. |
| Applications: General purpose, medical equipment, telecommunications, test and measurement (ATE) |
|
