Product Description
Description: Reed Relay • Mounting: Through Hole (THT) • Contact Form: 2A DPST-NO • Coil Voltage: 5 VDC • Switching Voltage: < 500 VDC • Switching Current (max.): - • Option: Standard • Special Feature: -
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting | Through Hole (THT) |
| Contact Form | 2A DPST-NO |
| Coil Voltage | 5 VDC |
| Switching Voltage | < 500 VDC |
| Switching Current (max.) | - |
| Option | Standard |
| Special Feature | - |
| Coil Resistance (typ.) | - |
| Pull-In Voltage (VDC) | 3.5 |
| Drop-Out Voltage (VDC) | 0.75 |
| Nominal Coil Power (typ.) mw | - |
| Series Features |
| BE Series Reed Relay |
| Series Description: Our most versatile general purpose BE Series Reed Relay with many contact configuration options including up to 5 form A switches. Available in latching or high IR typical 10^13 ?. Plastic or metal housing, epoxy encapsulated. |
| Applications: Battery powered devices, general purpose, medical equipment, photovoltaic, telecommunications, test and measurement (ATE) |
|
