Product Description
Description: Reed Relay • Mounting: Through Hole (THT) • Contact Form: 1A SPST-NO • Coil Voltage: 5 VDC • Switching Voltage: < 1000 VDC • Switching Current (max.): 1.0 Amp • Option: Magnetic Shield • Special Feature: -
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting | Through Hole (THT) |
| Contact Form | 1A SPST-NO |
| Coil Voltage | 5 VDC |
| Switching Voltage | < 1000 VDC |
| Switching Current (max.) | 1.0 Amp |
| Option | Magnetic Shield |
| Special Feature | - |
| Coil Resistance (typ.) | 105 (140) |
| Pull-In Voltage (VDC) | 3.5 |
| Drop-Out Voltage (VDC) | 0.75 |
| Nominal Coil Power (typ.) mw | 238 (179) |
| Rated Power (max.) | 100 W |
| Carry Current (max.) | 2.5 A |
| Contact Resistance (max.) | 150 mOhm |
| Breakdown Voltage (min.) | 2.5 kVDC |
| Operating Time (max.) | 1.1 ms |
| Release Time (max.) | 0.1 ms |
| Insulation Resistance (typ.) | 1012 |
| Capacitance (typ.) | 0.5 pF |
| Shock Resistance (max.) | 50 g |
| Vibration Resistance (max.) | 20 g |
| Operating Temperature (max.) | -20 to 70 °C |
| Storage Temperature (max.) | -35 to 95 °C |
| Soldering Temperature (max.) | 260 °C |
| Series Features |
| BE Series Reed Relay |
| Series Description: Our most versatile general purpose BE Series Reed Relay with many contact configuration options including up to 5 form A switches. Available in latching or high IR typical 10^13 ?. Plastic or metal housing, epoxy encapsulated. |
| Applications: Battery powered devices, general purpose, medical equipment, photovoltaic, telecommunications, test and measurement (ATE) |
|
