Product Description
Standex Electronics VPA Series Magnetic Proximity Sensor; Analog; Ferrous Metals; 8V ~ 30V
Magnetic Proximity Sensor • Type: Hall Effect Sensor • Output Type: Analog • Actuator Material: Ferrous Metals • Termination Style: Connector • Frequency: 500 Hz • Voltage - Supply: 8V ~ 30V
Product Information
| Manufacturer | Standex Electronics |
| Product Category | Position, Proximity, Speed (Modules) |
| Product Sub Category | Magnetic Proximity Sensor |
| Series | VPA Series |
| Catalog Part Number | S12H-275VPA-RGCB2 |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Type | Hall Effect Sensor |
| Output Type | Analog |
| Actuator Material | Ferrous Metals |
| Termination Style | Connector |
| Frequency | 500 Hz |
| Voltage - Supply | 8V ~ 30V |
| Operating Temperature | -40°C ~ 110°C |
| Package / Case | Cylinder, Threaded - M12 |
Series Features
VPA Series Analog Ferrous Metal Proximity Sensor
Series DescriptionThe VPA series delivers high-performance analog sensing for ferrous metal targets, without contact and without compromise. Powered by Hall effect technology, these solid-state sensors offer repeatable, large-gap detection through air, aluminum, and other non-ferrous materials, ensuring long-lasting, bounce-free operation in demanding environments.
Whether you’re aligning steel components in automotive assemblies or detecting hidden ferrous targets in industrial systems, the VPA series offers reliable, analog sensing performance in a compact, easy-to-integrate package.
- Analog 0–5 V output proportional to target proximity
- Stable performance across wide temperature ranges
- Wear-free construction in compact, rugged housings
- Custom programming for precise, repeatable detection
- Flexible mounting options including threaded and flange styles
- Wide range of connector options with free end wires, cable harnesses with connectors, or integrated connectors
Inspect for steel components below the surface of aluminum extrusions
Proximity feedback of components in automation equipment
Monitor position of steel components in engines and transmissions
Determine alignment between assemblies moving parallel to each other
Indication of component alignment in agricultural and heavy equipment
Measuring steel shaft runout
Counting steel components on conveyor systems
Position feedback in robotic systems
Inspecting to verify materials are ferrous
Detect approaching assemblies before impact
