To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Schneider Electric |
| Manufacturer Product Number | 6225AXXSZS-DC3 |
| Description | Solid State Relay; 25 A - 280 V AC; 1A SPST-NO; 3…32 V DC; Zero-Crossing |
| Datasheet | Download Datasheet |
The Schneider Electric 6225AXXSZS-DC3 is a solid state relay with 1A SPST-NO output, rated 25 A at 280 V AC and switching 24 to 280 V AC, driven by a 3 to 32 V DC input and drawing 10 at 12 V DC mA.
Its SCR output switches on at the zero crossing, which suits lamps, heaters and solenoids and keeps lamp inrush down.
It mounts on heat sink SSR-HS-1, with thermal pad SSR-TP-1 (optional, for relays up to 50 A).
It has panel mounting and screw terminals.
| Category | |
| Manufacturer | Schneider Electric |
| Part Status | Discontinued |
| Alternate Part Numbers | W6225DSX-1 |
