To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Schneider Electric |
| Manufacturer Product Number | 3TX7116-5FF03C |
| Description | Power Relay; 3C 3PDT; 15 A; 110VDC; Socketable; Plug In; Mechanical Indicator |
The Schneider Electric 3TX7116-5FF03C is a power relay with 3C 3PDT contacts, rated 15 A and switching up to 300V, driven by a 110VDC coil.
It has Socketable mounting and Plug In terminals, contacts in Silver Alloy and is supplied with mechanical indicator.
| Category | |
| Manufacturer | Schneider Electric |
| Mounting Type | Socketable |
| Coil Voltage | 110VDC |
| Contact Configuration | 3C 3PDT |
| Contact Rating (A) | 15 |
| Switching Voltage | 300V - Max |
| Contact Material | Silver Alloy |
| Termination Style | Plug In |
| Must Drop-Out Voltage | 11 V |
| Features | Mechanical Indicator |
| Number of Poles | 3 |
| Approvals | UL, RoHS |
| Operate Time (ms) | 20 |
| Operating Temperature (°C) | -40...+55 |
| Mechanical Life | 10,000,000 cycles (200,000 cycles) |
