To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Picker Components |
| Manufacturer Product Number | PC740-2C-C-12DF |
| Description | Power Relay; 2C DPDT; 40 A; 12VDC; Non Latching |
| Datasheet | Download Datasheet |
The Picker Components PC740-2C-C-12DF is a power relay with 2C DPDT contacts rated 40 A, switching up to 250VAC, 25VDC. It runs on a 12VDC coil (non-latching).
Contact material: AgCdO2.
Mechanical life 10,000,000 operations, electrical life 100,000 at rated load. Operating temperature -40 to +85 °C; storage -40 to +85 °C. Approvals: UL / cUL (E318155).
| Category | |
| Manufacturer | Picker Components |
| Part Status | Non-Standard |
| Coil Voltage | 12VDC |
| Contact Configuration | 2C DPDT |
| Contact Rating (A) | 40 |
| Switching Voltage | 250VAC, 25VDC |
| Contact Material | AgCdO2 |
| Coil Type | Non Latching |
| Number of Poles | 2 |
| Approvals | UL / cUL (E318155) |
| Operating Temperature | -40...+85 °C (-40...+85) |
| Mechanical Life | 10,000,000 cycles (100,000 cycles) |
