To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Picker Components |
| Manufacturer Product Number | PC673-2A-SD-220DLT |
| Description | Power Relay; 2A DPST-NO; 25 A; 220VDC; Non Latching; DIN Rail; Screw Terminal |
| Datasheet | Download Datasheet |
The Picker Components PC673-2A-SD-220DLT is a power relay with 2A DPST-NO contacts rated 25 A, switching up to 277VAC, 150VDC. It runs on a 220VDC coil (non-latching).
Mounting: din rail, screw terminal terminals. Contact material: Ag Alloy (Silver Oxide). Options on this part: finger guard, LED indicator, push-to-test button.
Coil current 8.64 mA, resistance 25474 Ω. Must operate at 165 V max and release at 33 V min. Operate time 30 ms, release time 30 ms.
Mechanical life 50,000,000 operations, electrical life 100,000 at rated load. Operating temperature -40 to +85 °C. Approvals: UL / cUL (E86876).
| Category | |
| Manufacturer | Picker Components |
| Mounting Type | DIN Rail |
| Coil Voltage | 220VDC |
| Contact Configuration | 2A DPST-NO |
| Contact Rating (A) | 25 |
| Switching Voltage | 277VAC, 150VDC |
| Contact Material | Ag Alloy (Silver Oxide) |
| Coil Current (mA) | 8.64 |
| Coil Resistance (ohm) | 25474 |
| Coil Type | Non Latching |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 165 V |
| Must Drop-Out Voltage | 33 V |
| Features | Finger Guard, LED Indicator, Push-to-Test Button |
| Number of Poles | 2 |
| Approvals | UL / cUL (E86876) |
| Operate Time (ms) | 30 |
| Release Time (ms) | 30 |
| Operating Temperature (°C) | -40...+85 |
| Mechanical Life | 50,000,000 cycles (100,000 cycles) |
