To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Picker Components |
| Manufacturer Product Number | PC375-2A-24S4-X |
| Description | Power Relay; 2A DPST-NO; 8 A; 24VDC; Non Latching; Through Hole; PC Pin |
| Datasheet | Download Datasheet |
The Picker Components PC375-2A-24S4-X is a power relay with 2A DPST-NO contacts rated 8 A, switching up to 440VAC, 125VDC. It runs on a 24VDC coil (non-latching).
Mounting: through hole, PC pin terminals. Construction: sealed. Contact material: AgSnO2.
Coil current 17.1 mA, resistance 1405 Ω. Must operate at 16.8 V max and release at 2.4 V min. Operate time 15 ms, release time 8 ms.
Mechanical life 10,000,000 operations, electrical life 100,000 at rated load. Operating temperature -40 to +85 °C. Approvals: UL / cUL (E86876).
| Category | |
| Manufacturer | Picker Components |
| Part Status | Non-Standard |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Configuration | 2A DPST-NO |
| Contact Rating (A) | 8 |
| Switching Voltage | 440VAC, 125VDC |
| Contact Material | AgSnO2 |
| Coil Current (mA) | 17.1 |
| Coil Resistance (ohm) | 1405 |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Must Operate Voltage | 16.8 V |
| Must Drop-Out Voltage | 2.4 V |
| Seal Rating | Sealed |
| Number of Poles | 2 |
| Approvals | UL / cUL (E86876) |
| Operate Time (ms) | 15 |
| Release Time (ms) | 8 |
| Operating Temperature (°C) | -40...+85 |
| Mechanical Life | 10,000,000 cycles (100,000 cycles) |
