To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Picker Components |
| Manufacturer Product Number | PC118-3C-P-C1-220A-GM-X |
| Description | Power Relay; 3C 3PDT; 10 A; 220VAC; Non Latching; Chassis Mount (Flange); PC Pin |
| Datasheet | Download Datasheet |
The Picker Components PC118-3C-P-C1-220A-GM-X is a power relay with 3C 3PDT contacts rated 10 A, switching up to 277VAC, 48VDC. It runs on a 220VAC coil (non-latching).
Mounting: chassis mount (flange), PC pin terminals. Contact material: AgCdO+Au. Options on this part: gold contacts, push-to-test button.
Coil resistance 14400 Ω. Must operate at 176 V max and release at 66 V min. Operate time 25 ms, release time 25 ms.
Mechanical life 10,000,000 operations, electrical life 100,000 at rated load. Operating temperature -40 to +85 °C; storage -40 to +155 °C. Approvals: UL, CUL (E86876).
| Category | |
| Manufacturer | Picker Components |
| Mounting Type | Chassis Mount (Flange) |
| Coil Voltage | 220VAC |
| Contact Configuration | 3C 3PDT |
| Contact Rating (A) | 10 |
| Switching Voltage | 277VAC, 48VDC |
| Contact Material | AgCdO+Au |
| Coil Resistance (ohm) | 14400 |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Must Operate Voltage | 176 V |
| Must Drop-Out Voltage | 66 V |
| Features | Gold Contacts, Push-to-Test Button |
| Number of Poles | 3 |
| Approvals | UL, CUL (E86876) |
| Operate Time (ms) | 25 |
| Release Time (ms) | 25 |
| Operating Temperature | -40...+85 °C (-40...+155) |
| Mechanical Life | 10,000,000 cycles (100,000 cycles) |
