To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Picker Components |
| Manufacturer Product Number | PC113-2C-P-C1-120A-LD-X |
| Description | Power Relay; 2C DPDT; 12 A; 120VAC; Non Latching; Chassis Mount (Flange); PC Pin |
| Datasheet | Download Datasheet |
The Picker Components PC113-2C-P-C1-120A-LD-X is a power relay with 2C DPDT contacts rated 12 A, switching up to 300VAC, 48VDC. It runs on a 120VAC coil (non-latching).
Mounting: chassis mount (flange), PC pin terminals. Contact material: AgCdO. Options on this part: LED indicator.
Coil resistance 4550 Ω. Must operate at 96 V max and release at 36 V min. Operate time 25 ms, release time 25 ms.
Mechanical life 10,000,000 operations, electrical life 100,000 at rated load. Operating temperature -40 to +85 °C; storage -40 to +155 °C. Approvals: UL, CUL (E86876).
| Category | |
| Manufacturer | Picker Components |
| Mounting Type | Chassis Mount (Flange) |
| Coil Voltage | 120VAC |
| Contact Configuration | 2C DPDT |
| Contact Rating (A) | 12 |
| Switching Voltage | 300VAC, 48VDC |
| Contact Material | AgCdO |
| Coil Resistance (ohm) | 4550 |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Must Operate Voltage | 96 V |
| Must Drop-Out Voltage | 36 V |
| Features | LED Indicator |
| Number of Poles | 2 |
| Approvals | UL, CUL (E86876) |
| Operate Time (ms) | 25 |
| Release Time (ms) | 25 |
| Operating Temperature | -40...+85 °C (-40...+155) |
| Mechanical Life | 10,000,000 cycles (100,000 cycles) |
