Product Description
Description: Power Relays • Coil Voltage: 12 VDC • Contact Configuration: 1A SPST-NO • Contact Current: 10 A • Coil Type: Single Side Stable • Mounting : PC Pins • Enclosure: Sealed • Insulation System: Class F (155°C) • Coil Sensitivity: Sensitive 200 mW
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Coil Voltage | 12 VDC |
| Contact Configuration | 1A SPST-NO |
| Contact Current | 10 A |
| Coil Type | Single Side Stable |
| Mounting | PC Pins |
| Enclosure | Sealed |
| Insulation System | Class F (155°C) |
| Coil Sensitivity | Sensitive 200 mW |
| Contact Material | AgCdO (Silver Cadmium Oxide) |
| Maximum Switching Power | 150 W, 1,250 VA |
| Maximum Switching Voltage | 30 VDC, 277 VAC |
| Initial Contact Resistance | 100 m? max. |
| Service Life | Mechanical 1 x 107 operations Electrical 1 x 105 operations |
| Operate Time | 8 msec max. |
| Release Time | 5 msec max |
| Insulation Resistance | 1,000 M? min. at 500 VDC |
| Dielectric Strength | 1,000 V, 50 Hz Between Contacts 2,500 V, 50 Hz Between Contact and Coil |
| Shock Resistance | 100 m/s2, 11ms, |
| Vibration Resistance | 10 Hz - 55 Hz DA 1.5 mm |
| Terminal Strength | 10 N |
| Solderability | 260°C for 5 seconds |
| Operating Temperature | - 40°C to 105°C |
| Relative Humidity | 95% (at 35°C) |
| Series Features |
| PC835 Series 10 Amp Subminiature PCB Power Relay |
| Series Description: |
|
