    ASX22006

    Manufacturer Panasonic
    Manufacturer Product Number ASX22006

    This item is out of stock. Please submit an RFQ or call 800-526-5376 for pricing and delivery.

    Product Description

    This product has been Discontinued

    Description: Signal Relay • Coil Voltage: 6 VDC • Contact Configuration: 2C DPDT • Current: 10 mAmps • Mounting: PC Board • Operating Function: 2 Coil Latching

          Product Information       Resources
    ManufacturerPanasonic Electric Works
    Product Category Relays
    Product Sub Category Signal Relays
    SeriesASX Series

      Download DatasheetFALSE
          Specifications
    Product Attribute
    		Attribute Value
    Mounting TypeThrough Hole
    Coil Voltage6VDC
    Contact FormDPDT (2 Form C)
    Contact Rating (Current)10 mA
    Switching Voltage10VDC - Max
    Coil Current11.7 mA
    Coil TypeLatching, Dual Coil
    Features-
    Termination StylePC Pin
    Seal Rating-
    Coil Insulation-
    Must Operate Voltage4.8 VDC
    Must Release Voltage-
    Operate Time5 ms
    Release Time5 ms
    Operating Temperature-40°C ~ 70°C
    Contact MaterialSilver Palladium (AgPd), Gold (Au)
