Product Description
Optifuse ANS Series Automotive Fuse; 4 A; Pink; Requires Holder; 2 Terminal; 32 V; Blade, Mini (Low Pro)
Automotive Fuse • Mounting Type: Requires Holder • Fuse Type: 2 Terminal • Current Rating (Amps): 4 A • Voltage Rating - DC: 32 V • Package / Case: Blade, Miniature (Low Profile) • Size / Dimension: 0.433" L x 0.154" W x 0.344" H (11.00mm x 3.91mm x 8.75mm) • Color: Pink
Product Information
| Manufacturer | Optifuse |
| Product Category | Fuse |
| Product Sub Category | Automotive Fuse |
| Series | ANS Series |
| Catalog Part Number | ANS-4A |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Mounting Type | Requires Holder |
| Fuse Type | 2 Terminal |
| Current Rating (Amps) | 4 A |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 32 V |
| Response Time | - |
| Breaking Capacity @ Rated Voltage | 1kA |
| Package / Case | Blade, Miniature (Low Profile) |
| Size / Dimension | 0.433" L x 0.154" W x 0.344" H (11.00mm x 3.91mm x 8.75mm) |
| Body Material | PA66 |
| Terminal Material | Zinc Alloy |
| Approval Agency | ISO8820, SAE |
| Color | Pink |
Series Features
ANS-10AANS
Series DescriptionBlade - Mini Style - Low Profile
- With the same housing height and width as our Mini style blade fuses, this fuse is engineered to save more space and weight by utilizing blade terminals that do not extend the length of the plastic housing body.
- Designed with industry-standard color coding for easy amperage identification.
- NEW: Select products are available in attractive retail packaging including blister & clamshell packs and convenient multi amperage assortment packs.
