To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | OptiFuse |
| Manufacturer Product Number | ANE-M-40A |
| Description | Automotive Fuse; 40 A; 32 VDC; Limiter (ANL Type) |
| Datasheet | Download Datasheet |
The OptiFuse ANE-M-40A is a 40 A ANL-type limiter automotive fuse, rated 32 VDC.
It fits bolt-down limiter (ANL) fuse holders.
It interrupts 3000 A @ 32 VDC. Opening times, as a share of the rating: 150%: min. 1 h; 220%: max. 60 s; 250%: 0.8-10 s; 400%: 0.2-2 s.
Construction: body fiberglass; terminals copper alloy, silver plated.
It is ignition protected to SAE J1171, for engine and fuel compartments.
| Category | |
| Manufacturer | OptiFuse |
| Model | ANE-M |
| Current Rating (A) | 40 |
| Voltage Rating | 32 VDC |
| Fuse Style | Limiter (ANL Type) |
| Fits | Bolt-down limiter (ANL) fuse holders |
| Interrupting Rating | 3000 A @ 32 VDC |
| Opening Time | 150%: min. 1 h; 220%: max. 60 s; 250%: 0.8-10 s; 400%: 0.2-2 s |
| Ignition Protection | SAE J1171 |
| Terminal Material | Copper Alloy, Silver Plated |
| Body Material | Fiberglass |
