To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | OptiFuse |
| Manufacturer Product Number | 642030 |
| Description | Automotive Circuit Breaker; 30 A; 32 VDC; Type III - Manual Reset |
| Datasheet | Download Datasheet |
The OptiFuse 642030 is a 30 A mid-range stud automotive circuit breaker with manual reset (SAE J553 Type III), rated 32 VDC.
It is panel mount (#8-32 threaded inserts); its terminals are #10-32 studs.
It interrupts 2500 A @ 32 VDC (ABYC E-11). Trip times at 25 °C, as a share of the rating: 100%: hold, no trip ( ≥ 30 min); 135%: trips within 30 min; 200%: 8.0-40.0 s; 300%: 1.2-12.0 s; 400%: 0.6-5.0 s. It operates from -40 to +85 °C.
It is ignition protected to SAE J1171, for use in engine and fuel compartments and sealed to IP66.
Tested to SAE J553, ABYC E-11.
| Category | |
| Manufacturer | OptiFuse |
| Model | 642 |
| Current Rating (A) | 30 |
| Voltage Rating - DC | 32 VDC |
| Reset Type | Type III - Manual Reset |
| Breaker Style | Mid-Range Stud |
| Mounting Type | Panel Mount (#8-32 threaded inserts) |
| Terminal Type | #10-32 Stud |
| Interrupting Rating | 2500 A @ 32 VDC (ABYC E-11) |
| Trip Characteristics | 100%: hold, no trip ( ≥ 30 min); 135%: trips within 30 min; 200%: 8.0-40.0 s; 300%: 1.2-12.0 s; 400%: 0.6-5.0 s |
| Operating Temperature (°C) | -40 to +85 |
| Standards | SAE J553, ABYC E-11 |
| Number of Poles | 1 |
