To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | OptiFuse |
| Manufacturer Product Number | RALT-260 |
| Description | PTC Fuse; 2.6 A; 24 VDC; Strap |
| Datasheet | Download Datasheet |
The OptiFuse RALT-260 is a 2.6 A hold battery-strap resettable PTC fuse, rated 24 VDC maximum.
A PTC fuse carries its hold current indefinitely; on an overcurrent it heats, its resistance rises sharply and it limits the current to a trickle, then resets on its own once the fault is removed and power is cycled. This one always trips at 5.2 A.
It withstands a fault current of up to 100 A at rated voltage. Resistance: minimum 0.025 Ω, maximum 0.042 Ω, 0.076 Ω maximum one hour after tripping. Tripped, it dissipates typically 2.3 W. It operates from -40 to +85 °C.
Construction: outline 26.0 x 11.9 x 1.0 mm (max.); nickel strap, 0.13 mm.
| Category | |
| Manufacturer | OptiFuse |
| Model | RALT |
| Hold Current (A) | 2.6 |
| Trip Current (A) | 5.2 |
| Max Voltage | 24 VDC |
| Max Fault Current (A) | 100 |
| Power Dissipation (W) | 2.3 |
| Min Resistance (Ω) | 0.025 |
| Max Resistance (Ω) | 0.042 |
| Max Resistance 1 h After Trip (Ω) | 0.076 |
| Mounting Style | Battery Strap |
| Size | 26.0 x 11.9 x 1.0 mm (max.) |
| Lead Material | Nickel strap, 0.13 mm |
| Operating Temperature (°C) | -40 to +85 |
