To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | OptiFuse |
| Manufacturer Product Number | BLC-108-G |
| Description | Fuse Block; ATO/ATC Blade; Gnd; 8-Pos; 25/100A; 25 A; 32 VDC |
| Datasheet | Download Datasheet |
The OptiFuse BLC-108-G is a 8-position fuse block with ground bus for regular blade (ATO/ATC) fuses, rated 25 A per circuit, 100 A total, 32 VDC.
Terminals: 0.250 in quick-connect outputs, #10-32 input stud. Cover: optional (BLC-108-C).
Construction: polycarbonate (UL 94V-2); tin plated copper contacts.
| Category | |
| Manufacturer | OptiFuse |
| Fuse Type | Regular blade (ATO/ATC) |
| Holder Type | Fuse block with ground bus |
| Positions | 8 |
| Max Current (A) | 25 |
| Circuit Ratings | 25 A per circuit; 100 A total |
| Voltage Rating | 32 VDC |
| Terminal Type | 0.250 in quick-connect outputs, #10-32 input stud |
| Cover | Optional (BLC-108-C) |
| Housing Material | Polycarbonate (UL 94V-2) |
| Contact Material | Tin plated copper |
