To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | OptiFuse |
| Manufacturer Product Number | MOCB2-TP-40A |
| Description | Automotive Circuit Breaker; 40 A; 12 VDC; Type II - Modified Reset |
| Datasheet | Download Datasheet |
The OptiFuse MOCB2-TP-40A is a 40 A quick connect automotive circuit breaker with modified reset (SAE J553 Type II), staying tripped while the fault and power remain and resetting once power is removed, rated 12 VDC.
It is wired with 0.250 in quick connect terminals.
Its body is plastic.
Trip times at 25 °C, as a share of the rating: 100% ± 1.5%: >30 min; 135% ± 1.5%: <30 min; 200% ± 1.5%: <1 min.
Tested to SAE J553.
| Category | |
| Manufacturer | OptiFuse |
| Model | MOCB2-TP |
| Current Rating (A) | 40 |
| Voltage Rating - DC | 12 VDC |
| Reset Type | Type II - Modified Reset |
| Breaker Style | Quick Connect |
| Mounting Type | Wired with 0.250 in quick connect terminals |
| Terminal Type | 0.250 in Quick Connect |
| Trip Characteristics | 100% ± 1.5%: >30 min; 135% ± 1.5%: <30 min; 200% ± 1.5%: <1 min |
| Standards | SAE J553 |
| Body Material | Plastic |
| Number of Poles | 1 |
