Product Description
Description: Signal Relays • Coil Voltage: 4.5 VDC • Contact Configuration: 2C DPDT • Current: 2 Amp • Function: Single Side Stable • Mounting: PC Board • Sealed: Yes
| Product Information | Resources |
|
|
| Specifications |
| Product Attribute | Attribute Value |
| Coil Voltage | 4.5 VDC |
| Contact Configuration | 2C DPDT |
| Current | 2 Amp |
| Function | Single Side Stable |
| Mounting | PC Board |
| Sealed | Yes |
| Initial Contact Resistance | 50 |
| Nominal Operating Power | 200 mW |
| Operate Time (Excluding bounce) | Approx. 5.5 ms without diode (at nominal coil voltage) |
| Release Time (Excluding bounce) | Approx. 2 ms without diode (at nominal coil voltage) |
| Insulation Resistance | 1000 M ohms at 500 VDC |
| Withstanding Voltage | Between open contacts: 500 VAC (for one minute) Between adjacent contact: 1000 VAC (for one minute) 1500 V surge (10x160 ?s) Between coil and contacts: 1000 VAC (for one minute) , 1500 V surge (2x10 ?s) |
| Shock Resistance | 294 m/s2 (75G) (misoperation) 980 m/s2 (100G) (destructive failure) |
| Vibration Resistance | 10 to 55 Hz, double amplitude 1.5 mm (misoperation) 10 to 55 Hz, double amplitude 5 mm(destructive failure) |
| Ambient Temperature | -40 to +85°C |
| Coil Temperature Rise | Approx. 22?C at nominal coil voltage (200 mW) |
| Series Features |
| MR82 SERIES |
| Series Description: This series is a plastic sealed miniature relay designed to offer completely dust and waterproof package with bifurcated and crossbar contacts for assuring high reliability. |
| Applications: Electronic switching systems, test equipment, LAN systems, modems, facsimile, factory automation systems, audiovisual aids, and other electronic equipment |
|
