To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Metz Connect |
| Manufacturer Product Number | ASP0641206 |
| Description | Spring TB; 12-pos; 3.81mm; Plug; Vert; PB; 8A; 150V; Parallel; PA66; Green |
| Datasheet | Download Datasheet |
The Metz Connect ASP0641206 is a 12-position spring-clamp terminal block plug on a 3.81 mm (0.150") pitch, with vertical (0°) wire entry. It is UL rated 8 A at 150 V for 28-16 AWG wire, and IEC rated 8 A at 250 V (OVC III, PD 2) for 0.08-1.5 mm² wire.
The housing is green polyamide PA66, rated UL 94 V-0, insulation group CTI 600, IP20 protection. Wires are held by a spring-steel clamp opened with a push-button. Strip wires 9 mm. Plug contacts are tin bronze (CuSn), tin plated. It operates from -40°C to 105°C.
Features: wire entry parallel to plug. Approvals: cULus, SEV (UL file E121004).
| Category | |
| Manufacturer | Metz Connect |
| Number of Positions | 12 |
| Pitch | 3.81 mm (0.150") |
| Block Type | Pluggable Plug |
| Wire Entry Angle | 0° (Vertical) |
| Actuation | Push-Button |
| Current Rating | 8 A |
| Voltage Rating | 150 V |
| Wire Range | 28-16 AWG |
| IEC Current Rating | 8 A |
| IEC Voltage Rating | 50 V (OVC III, PD 3), 250 V (OVC III, PD 2), 250 V (OVC II, PD 2) |
| Rated Impulse Voltage | 2.5 kV |
| IEC Wire Range | 0.08-1.5 mm² |
| Strip Length | 9 mm |
| Color | Green |
| Housing Material | Polyamide PA66 |
| Flammability Rating | UL 94 V-0 |
| Contact Material | Tin Bronze (CuSn), Tin Plated |
| Spring Material | Spring Steel |
| Operating Temperature | -40°C to 105°C |
| Protection Rating | IP20 |
| Clearance / Creepage | 1.9 mm |
| Insulation Material Group | CTI 600 |
| Glow-Wire Rating | GWFI 960°C / GWIT 775°C |
| Features | Wire Entry Parallel to Plug |
| UL File | E121004 |
| Approvals | cULus, SEV |
