To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Metz Connect |
| Manufacturer Product Number | ASP0250404 |
| Description | Spring TB; 4-pos; 5.00mm; Plug; 90°; Lever; 8A; 300V; Stackable Perp; PA46; Gray |
| Datasheet | Download Datasheet |
The Metz Connect ASP0250404 is a 4-position spring-clamp terminal block plug on a 5.00 mm (0.197") pitch, with horizontal (90°) wire entry. It is UL rated 8 A at 300 V for 28-16 AWG wire, and IEC rated 200 V (OVC III, PD 2) for 0.08-1.5 mm² wire.
The housing is gray polyamide PA46, rated UL 94 V-0, insulation group CTI 400, IP20 protection. Wires are held by a spring-steel clamp opened with an eccentric lever. Strip wires 4 mm. Plug contacts are tin bronze (CuSn), tin plated. It operates from -40°C to 105°C.
Features: stackable without loss of poles, wire entry perpendicular to plug. Approvals: cULus, SEV (UL file E121004).
| Category | |
| Manufacturer | Metz Connect |
| Number of Positions | 4 |
| Pitch | 5.00 mm (0.197") |
| Block Type | Pluggable Plug |
| Wire Entry Angle | 90° (Horizontal) |
| Actuation | Eccentric Lever |
| Current Rating | 8 A |
| Voltage Rating | 300 V |
| Wire Range | 28-16 AWG |
| IEC Voltage Rating | 32 V (OVC III, PD 3), 200 V (OVC III, PD 2), 200 V (OVC II, PD 2) |
| Rated Impulse Voltage | 1.5 kV |
| IEC Wire Range | 0.08-1.5 mm² |
| Strip Length | 4 mm |
| Color | Gray |
| Housing Material | Polyamide PA46 |
| Flammability Rating | UL 94 V-0 |
| Contact Material | Tin Bronze (CuSn), Tin Plated |
| Spring Material | Spring Steel |
| Operating Temperature | -40°C to 105°C |
| Protection Rating | IP20 |
| Clearance / Creepage | 3.7 mm |
| Insulation Material Group | CTI 400 |
| Features | Stackable Without Loss of Poles, Wire Entry Perpendicular to Plug |
| UL File | E121004 |
| Approvals | cULus, SEV |
