To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Mechatronics |
| Manufacturer Product Number | UF12B12-BTLR |
| Description | AC Axial Fan; 120x120x25mm; 115 VAC; 53 CFM; 2000 RPM; Ball; QC Term |
| Datasheet | Download Datasheet |
The Mechatronics UF12B12-BTLR is a 120 x 120 x 25 mm 115 VAC axial fan moving 53 CFM (1.50 m³/min) at 2,000 RPM, with a maximum static pressure of 0.11 inH2O (2.79 mmH2O) and a noise level of 33 dBA (60 Hz figures).
It runs on ball bearings and connects with 0.110 in quick-connect terminals.
It draws 0.11 A / 11 W. It has a shaded-pole motor, with impedance protection. The frame is die-cast aluminum. The impeller is UL94V-0 PBT Plastic. It operates from -40 to +70 °C and can be stored from -40 to +70 °C.
| Category | |
| Manufacturer | Mechatronics |
| Model | UF12B12-L |
| Fan Type | Axial |
| Dimensions | 120 x 120 x 25 mm (4.69 x 4.69 x 0.98 in) |
| Rated Voltage | 115 VAC |
| Air Flow | 53 CFM (1.50 m3/min) |
| Max Static Pressure | 0.11 inH2O (2.79 mmH2O) |
| Speed (RPM) | 2000 |
| Noise Level (dBA) | 33 |
| Input Power (W) | 11 |
| Rated Current (A) | 0.11 |
| Bearing Type | Ball |
| Termination | 0.110 in Quick-Connect Terminals |
| Airflow Direction | Air exhaust over struts |
| Motor Type | Shaded pole |
| Motor Protection | Impedance protection |
| Frame Material | Die-cast Aluminum |
| Impeller Material | UL94V-0 PBT Plastic |
| Insulation Class | Class B |
| Operating Temperature | -40...+70 °C (-40...+70 °C) |
