To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Mechatronics |
| Manufacturer Product Number | LPT60B99-BWHR |
| Description | EC Axial Fan; 60x60x25mm; 100-240 VAC; 19.1 CFM; 3900RPM; Ball; Lead Wires |
| Datasheet | Download Datasheet |
The Mechatronics LPT60B99-BWHR is a 60 x 60 x 25 mm 100-240 VAC EC axial fan moving 19.1 CFM (0.54 m³/min) at 3,900 RPM, with a maximum static pressure of 0.17 inH2O (4.32 mmH2O) and a noise level of 60 dBA.
It runs on ball bearings and connects with lead wires.
It draws 0.04 A / 2.4 W. It has a Brushless EC motor, with locked rotor protection. Frame and impeller are UL94V-0 PBT Plastic. It operates from -10 to +70 °C and can be stored from -20 to +70 °C.
| Category | |
| Manufacturer | Mechatronics |
| Fan Type | Axial |
| Dimensions | 60 x 60 x 25 mm (2.36 x 2.36 x 1.00 in) |
| Rated Voltage | 100-240 VAC |
| Air Flow | 19.1 CFM (0.54 m3/min) |
| Max Static Pressure | 0.17 inH2O (4.32 mmH2O) |
| Speed (RPM) | 3900 |
| Noise Level (dBA) | 60 |
| Input Power (W) | 2.4 |
| Rated Current (A) | 0.04 |
| Bearing Type | Ball |
| Termination | Lead Wires |
| Airflow Direction | Air exhaust over struts |
| Motor Type | Brushless EC |
| Motor Protection | Locked rotor protection |
| Frame Material | UL94V-0 PBT Plastic |
| Impeller Material | UL94V-0 PBT Plastic |
| Operating Temperature | -10...+70 °C (-20...+70 °C) |
