Product Description
Mechatronics LPT15P99-BWHR Series AC Axial Fan; 172x150x38mm; Rect; 100 ~ 240VAC; 57.0dB; 220.0 CFM (6.16m³/min); Ball
AC Axial Fan • Voltage - Rated: 100 ~ 240VAC • Shape: Rectangular • Frame Size: 172x150x38mm • Air Flow: 220.0 CFM (6.16m³/min) • Static Pressure: 0.063 in H2O (15.7 Pa) • Bearing Type: Ball • Fan Type: Tubeaxial • Noise: 57.0dB • Power (Watts): 22.00W • RPM: 3000 RPM • Termination: 2 Terminals
Product Information
| Manufacturer | Mechatronics |
| Product Category | Fans & Blowers |
| Product Sub Category | AC Axial Fan |
| Series | LPT15P99-BWHR Series |
| Catalog Part Number | LPT15P99-BWHR-2EM-EX |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Voltage - Rated | 100 ~ 240VAC |
| Shape | Rectangular |
| Frame Size | 172x150x38mm |
| Air Flow | 220.0 CFM (6.16m³/min) |
| Static Pressure | 0.063 in H2O (15.7 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Electronic Commutation (EC) |
| Noise | 57.0dB |
| Power (Watts) | 22.00W |
| RPM | 3000 RPM |
| Termination | 2 Terminals |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Approval Agency | ATEX |
| Weight | 1.543 lb (700.0 g) |
