To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Mechatronics |
| Manufacturer Product Number | LPC80B99-BWER |
| Description | EC Axial Fan; 80x80x25mm; 100-240 VAC; 53 CFM; 4500 RPM; Ball; Lead Wires |
| Datasheet | Download Datasheet |
The Mechatronics LPC80B99-BWER is a 80 x 80 x 25 mm 100-240 VAC EC axial fan moving 53 CFM (1.50 m³/min) at 4,500 RPM, with a maximum static pressure of 0.25 inH2O (6.30 mmH2O) and a noise level of 45 dBA.
It runs on ball bearings and connects with lead wires.
It draws 5 W. It has an electronically commutated motor, with locked rotor protection. The frame is magnesium die cast. The impeller is UL94V-0 PBT Plastic. It operates from -10 to +70 °C and can be stored from -20 to +70 °C.
| Category | |
| Manufacturer | Mechatronics |
| Model | LPC80B99-E |
| Fan Type | Axial |
| Dimensions | 80 x 80 x 25 mm (3.15 x 3.15 x 0.98 in) |
| Rated Voltage | 100-240 VAC |
| Air Flow | 53 CFM (1.50 m3/min) |
| Max Static Pressure | 0.25 inH2O (6.30 mmH2O) |
| Speed (RPM) | 4500 |
| Noise Level (dBA) | 45 |
| Input Power (W) | 5 |
| Bearing Type | Ball |
| Termination | Lead Wires |
| Airflow Direction | Air exhaust over struts |
| Motor Type | Electronically commutated |
| Motor Protection | Locked rotor protection |
| Frame Material | Magnesium die cast frame |
| Impeller Material | UL94V-0 PBT Plastic |
| Operating Temperature | -10...+70 °C (-20...+70 °C) |
