To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Mechatronics |
| Manufacturer Product Number | LPC15P23-BTER |
| Description | EC Axial Fan; 172x150x51mm; 230 VAC; 290 CFM; 4000 RPM; Ball; QC Term |
| Datasheet | Download Datasheet |
The Mechatronics LPC15P23-BTER is a 172 x 150 x 51 mm 230 VAC EC axial fan moving 290 CFM (8.20 m³/min) at 4,000 RPM, with a maximum static pressure of 0.70 inH2O (17.50 mmH2O) and a noise level of 61 dBA.
It runs on ball bearings and connects with 0.110 in quick-connect terminals.
It draws 29 W. It has an electronically commutated motor, with locked rotor protection. The frame is magnesium die cast. The impeller is UL94V-0 PBT Plastic. It operates from -10 to +70 °C and can be stored from -20 to +70 °C.
| Category | |
| Manufacturer | Mechatronics |
| Model | LPC15P23-E |
| Fan Type | Axial |
| Dimensions | 172 x 150 x 51 mm (6.77 x 5.94 x 2 in) |
| Rated Voltage | 230 VAC |
| Air Flow | 290 CFM (8.20 m3/min) |
| Max Static Pressure | 0.70 inH2O (17.50 mmH2O) |
| Speed (RPM) | 4000 |
| Noise Level (dBA) | 61 |
| Input Power (W) | 29 |
| Bearing Type | Ball |
| Termination | 0.110 in Quick-Connect Terminals |
| Airflow Direction | Air exhaust over struts |
| Motor Type | Electronically commutated |
| Motor Protection | Locked rotor protection |
| Frame Material | Magnesium die cast frame |
| Impeller Material | UL94V-0 PBT Plastic |
| Operating Temperature | -10...+70 °C (-20...+70 °C) |
