To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Model | TD-8 |
| Manufacturer Product Number | TD-80822-40 |
| Description | TDR; 0.1...102.3 s; Flasher (OFF 1st); 120V AC/DC; 2C DPDT |
| Datasheet | Download Datasheet |
The Macromatic TD-80822-40 is a time delay relay with 2C DPDT output and rated 10 A at 240 V AC, 10 A at 30 V DC, driven by a 120V AC/DC input.
It is adjustable from 0.1 to 102.3 s and set by DIP switches, digital set.
It is a Flasher (OFF 1st) timer.
Upon application of control voltage, the time delay (t) begins. At the end of the time delay (t), the output is energized and remains in that condition for the time delay (t). At the end of the time delay (t), the output is de-energized and the sequence repeats until the control voltage is removed.
It has Socketable mounting and Plug In terminals.
