To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | THS-1514D-33R1-04R1 |
| Description | TDR; 1...100 min; 0.05...5 s; Repeat Cycle (On 1st); 12-125V DC; Remote Adj (R1/R1) |
| Datasheet | Download Datasheet |
The Macromatic THS-1514D-33R1-04R1 is a time delay relay with 1A SPST-NO output and rated 1 A continuous, 10 A inrush at 65 °C, pilot duty, driven by a 12-125V DC input.
It is adjustable from 1 to 100 min and set by a remote potentiometer.
Its second delay adjusts from 0.05 to 5 s.
It is a Repeat Cycle (On 1st) timer.
Upon application of control voltage, the output is energized and the time delay (t1) begins. At the end of the time delay (t1), the output is de-energized and remains in that condition for the time delay (t2). At the end of this time delay, the output is energized and the sequence repeats until input voltage is removed.
Build option: remote adjustment (R1/R1).
It has Surface Mounting and 0.250" (6.3mm) quick-connect terminals.
| Category | |
| Manufacturer | Macromatic |
| Model | THS-1 |
