To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | PAP240 |
| Description | Phase Monitor Relay; 3-Phase; 240V AC; 180...230 V AC; 1C SPDT |
| Datasheet | Download Datasheet |
The Macromatic PAP240 is a Plug-In phase monitor relay with 1C SPDT output and rated 10 A at 277 V AC, 7 A at 30 V DC, driven by a 240V AC input.
It watches all three phases for phase loss, phase reversal and undervoltage, measuring true RMS with full-wave monitoring.
The undervoltage trip point is adjustable from 75 to 95% of the line voltage setting, which is 180 to 230 V AC on this part, and resets at +3% of the trip setting.
It drops out 100 ms after a lost or reversed phase, 4 s after an undervoltage and re-energises 1 s after the fault clears.
It has Socketable mounting and Plug In terminals.
