| Manufacturer | Macromatic |
| Manufacturer Product Number | PAP120 |
| Description | Phase Monitor Relay; 3-Phase; (110...120)V AC; 90...115 V AC; 1C SPDT |
| Datasheet | Download Datasheet |
The Macromatic PAP120 is a Plug-In phase monitor relay with 1C SPDT output and rated 10 A at 240 V AC, driven by a (110...120)V AC input.
It watches all three phases for phase loss, phase reversal and undervoltage.
The undervoltage trip point is adjustable from 75 to 95% of the line voltage setting, which is 90 to 115 V AC on this part, and resets at +3% of the trip setting.
It has Socketable mounting and Plug In terminals.
| Category | |
| Manufacturer | Macromatic |
| Part Status | Discontinued |
| Model | PAP |
| Sub-Family | Plug-In |
| Monitoring Function | Phase Loss, Phase Reversal and Undervoltage |
| Number of Phases | 3-Phase |
| Input Voltage | (110...120)V AC |
| Undervoltage Trip Range | 90...115 V AC |
| Undervoltage Trip Adjustment | Adjustable from 75 to 95% of the line voltage setting; resets at +3% of the trip setting |
| Status Indicator | Red LED on when all conditions are normal, and off when a fault condition has occurred |
| Contact Configuration | 1C SPDT |
| Output Rating | 10 A at 240 V AC |
| Single Phase Motor Rating | 1/3 HP at 240 V AC, 1/6 HP at 240 V AC on the NC contact |
| Number of Poles | 1 |
| Mounting Type | Socketable |
| Termination Style | Plug In |
| Socket Family | 8 Pin Octal; a 600 V-rated socket such as the Macromatic 70169-D is required above 300 V |
| Electrical Life | 100,000 |
| Weight (lb) | 0.25 |
