To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | VWKP110D |
| Description | Voltage Monitor Relay; Voltage Band (Window); 110V DC; 0.1...10 s adjustable; DPDT |
| Datasheet | Download Datasheet |
The Macromatic VWKP110D is a voltage monitor relay with DPDT output and rated 10 A at 240 V AC, 7 A at 30 V DC, driven by a 110V DC input.
It watches the supply for voltage band (window), measuring true RMS.
Its upper threshold adjusts across 83 to 138V DC, and its lower across 62 to 130V DC.
The drop-out point is adjustable, 75 to 95% of the over-voltage setting.
It trips after 0.1 to 10 s (adjustable) and picks up after 0.5 s.
It has Socketable mounting and Plug In terminals.
| Category | |
| Manufacturer | Macromatic |
