To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | VMP120A |
| Description | Voltage Monitor Relay; Over/Undervoltage; 120V AC; 0.5 s fixed; DPDT |
| Datasheet | Download Datasheet |
The Macromatic VMP120A is a voltage monitor relay with DPDT output and rated 10 A at 240 V AC, 7 A at 30 V DC, driven by a 120V AC input.
It watches the supply for Over/Undervoltage, measuring true RMS.
Its upper threshold adjusts across 90 to 150V AC, and its lower across 68 to 142V AC.
The drop-out point is fixed at 95% of the pick-up setting.
It trips after 0.5 s (fixed) and picks up after 0.5 s.
It has Socketable mounting and Plug In terminals.
