To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | LCP2A250F20 |
| Description | Liquid Level Relay; Pump Up; 120V AC; 1K...250K ohms; 20 s factory-fixed; Socketable |
| Datasheet | Download Datasheet |
The Macromatic LCP2A250F20 is a liquid level control relay rated 10 A at 240 V AC, 7 A at 28 V DC, driven by a 120V AC input.
It controls the level of a conductive liquid, pumping up to fill the tank.
It switches on a single probe at one level, with a factory-set 20 s delay so the pump cannot cycle on a moving surface.
The setpoint covers 1K to 250K ohms between probe and common, so it is the conductivity of the liquid that decides the part.
The probe is pulsed with 5 V DC rather than held at a steady potential, which is what stops it electroplating away in service.
It has Socketable mounting and Plug In terminals.
