To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | THS-1094D-36 |
| Description | Time Delay Relay; 10...1,000 s; Flasher (ON 1st); 12-125V DC; 1A SPST-NO |
| Datasheet | Download Datasheet |
The Macromatic THS-1094D-36 is a time delay relay with 1A SPST-NO output and rated 1 A continuous, 10 A inrush at 65 °C, pilot duty, driven by a 12-125V DC input.
It is adjustable from 10 to 1,000 s and set by an onboard knob.
It is a Flasher (ON 1st) timer.
Upon application of control voltage, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized and remains in that condition for the time delay (t). At the end of the time delay (t), the output is energized and the sequence repeats until the control voltage is removed.
It has Surface Mounting and 0.250" (6.3mm) quick-connect terminals.
| Category | |
| Manufacturer | Macromatic |
| Model | THS-1 |
| Output Technology | Solid State |
| Timing Function | Flasher (ON 1st) |
| Delay Time | 10...1,000 s |
| Timing Adjustment Method | Onboard knob |
| Timing Initiate Method | Input Voltage |
| Contact Configuration | 1A SPST-NO |
| Output Rating | 1 A continuous, 10 A inrush at 65 °C, pilot duty |
| Input Voltage | 12-125V DC |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -28...+65 °C (-40...+85 °C) |
| Approvals | UL Recognized (E236146) |
| Setting Accuracy (%) | Maximum setting +5%/-0%, minimum setting +0%/-50% |
| Repeatability (%) | +0.1% or +0.04 s, whichever is greater, at constant voltage and temperature |
| Start-Up Time | 0.05 s |
| Maintain Function Time | 0.01 s |
| Input Operating Range | +10%/-15% of nominal, AC at 50/60 Hz and DC |
| Rated Power | 1 VA |
