To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Model | THS-1 |
| Manufacturer Product Number | THS-1614D-33 |
| Description | Time Delay Relay; 1...100 min; Delayed Interval; 12-125V DC; 1A SPST-NO |
| Datasheet | Download Datasheet |
The Macromatic THS-1614D-33 is a time delay relay with 1A SPST-NO output and rated 1 A continuous, 10 A inrush at 65 °C, pilot duty, driven by a 12-125V DC input.
It is adjustable from 1 to 100 min and set by an onboard knob.
It is a Delayed Interval timer.
Upon application of input voltage, the time delay (t1) begins. At the end of the time delay (t1), the output is energized and remains in that condition for the time delay (t2). At the end of this time delay (t2), the output is de-energized. Input voltage must be removed to reset the time delay relay.
It has Surface Mounting and 0.250" (6.3mm) quick-connect terminals.
| Category | |
| Manufacturer | Macromatic |
