To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | THS-1124D-33T |
| Description | TDR; 1...100 min; Trig. On Delay; 12-125V DC; 1-Pin Trigger; 1A SPST-NO |
| Datasheet | Download Datasheet |
The Macromatic THS-1124D-33T is a time delay relay with 1A SPST-NO output and rated 1 A continuous, 10 A inrush at 65 °C, pilot duty, driven by a 12-125V DC input.
It is adjustable from 1 to 100 min and set by an onboard knob.
It is an On Delay (Switch Trigger) timer.
Upon application of control voltage, the time delay is ready to accept a trigger. When the trigger is applied, the time delay (t) begins. At the end of the time delay (t), the output is energized and remains in that condition as long as both the trigger and control voltage remain. If the trigger is removed during the time delay (t), the output remains de-energized & the time delay (t) is reset.
It is started by a control switch.
Build option: control switch common to pin 2 (single-pin trigger).
It has Surface Mounting and 0.250" (6.3mm) quick-connect terminals.
| Category | |
| Manufacturer | Macromatic |
| Model | THS-1 |
