To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Macromatic |
| Manufacturer Product Number | ARP120A2 |
| Description | Alternating Relay; Duplex; 2C DPDT; 120V AC; 11 Pin Octal; Socketable |
| Datasheet | Download Datasheet |
The Macromatic ARP120A2 is an alternating relay with 2C DPDT output and rated 10 A at 240 V AC, 10 A at 24 V DC, driven by a 120V AC input.
It alternates two loads on each opening of the control switch, so their run time evens out.
It is driven by one control switch: any isolated contact -- float, pressure, manual or a timing relay.
It plugs into an 11 Pin Octal socket.
This version has no selector switch; the R version of the same catalog number does.
It has Socketable mounting and Plug In terminals.
