| Manufacturer | Macromatic |
| Manufacturer Product Number | ARP012A2R |
| Description | Alternating Relay; Duplex; 2C DPDT; 12V AC/DC; 11 Pin Octal |
| Datasheet | Download Datasheet |
The Macromatic ARP012A2R is an alternating relay with 2C DPDT output and rated 10 A at 240 V AC, 10 A at 24 V DC, driven by a 12V AC/DC input.
It alternates two loads on each opening of the control switch, so their run time evens out.
It is driven by one control switch: any isolated contact -- float, pressure, manual or a timing relay.
It plugs into an 11 Pin Octal socket.
The selector switch is three-position: ALTERNATE, or lock LOAD 1 or LOAD 2 as the only load energised.
It has Socketable mounting and Plug In terminals.
