Product Description
Littelfuse Industrial Business Unit POWR-GARD® Medium Voltage Fuses; 30A; Class: -; Requires Holder; 5AG, 10mm x 38mm (Midget)
Specialty Fuse • Fuse Family: Medium Voltage Fuses • Mounting Type: Requires Holder • Fuse Type: Fast Acting • Current Rating (Amps): 30A • Response Time: Fast Blow • Class: - • Package / Case: 5AG, 10mm x 38mm (Midget)
Product Information
| Manufacturer | Littelfuse Industrial Business Unit |
| Product Category | Fuse |
| Product Sub Category | Specialty Fuse |
| Series | POWR-GARD® |
| Catalog Part Number | LNNB001 |
| Ordering Part Number | LNNB0001Z |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Fuse Family | Medium Voltage Fuses |
| Mounting Type | Requires Holder |
| Fuse Type | Fast Acting |
| Current Rating (Amps) | 30A |
| Response Time | Fast Blow |
| Applications | - |
| Features | - |
| Class | - |
| Breaking Capacity @ Rated Voltage | - |
| Package / Case | 5AG, 10mm x 38mm (Midget) |
| Size / Dimension | 0.406" Dia x 1.500" L (10.30mm x 38.00mm) |
| Voltage Rating - AC | - |
Series Features
POWR-GARD® MEDIUM VOLTAGE FUSES 2,400-38,000 VAC • Current-Limiting
Series DescriptionLittelfuse® offers a selection of E- and R-rated medium voltage fuses for the protection of trans formers, potential transformers, feeders, and motor circuits. Single, double, and triple barrel designs are available to cover a wide range of current, voltage, and interrupting  ratings. Conventional ferrule type, clip lock, and bolt-in mounting configurations are available for virtually any application. Hermetically sealed fuses for use in hazardous environments are also offered.
Series ApplicationsPower Transformer Protection, Potential Transformer Protection, Motor Controller Back-up Protection, Fused Switches, Feeder Circuits
