To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | LITTELFUSE |
| Manufacturer Product Number | SRP1-CBAZL-025NW-N |
| Description | Solid State Relay; 25 A - 240 V AC; 1A SPST-NO; 90…280 V AC; Zero-Crossing |
| Datasheet | Download Datasheet |
The Littelfuse SRP1-CBAZL-025NW-N is a solid state relay with 1A SPST-NO output, rated 25 A at 240 V AC and switching 24 to 280 V AC, driven by a 90…280 V AC input and drawing 7 mA.
Its back-to-back SCR output switches on at the zero crossing, which suits lamps, heaters and solenoids and keeps lamp inrush down.
It needs a heat sink, not included.
It has panel mounting and screw terminals.
| Category | |
| Manufacturer | LITTELFUSE |
| Model | SRP1-CB |
