To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | LITTELFUSE |
| Manufacturer Product Number | LFT606003CS |
| Description | Fuse Block; Class T; 3-Pos; 600 A; 600 V; Fits JLLS |
| Datasheet | Download Datasheet |
The Littelfuse LFT606003CS is a 3-position Class T fuse block, rated 600 A, 600 V.
Interrupting rating 200 kA SCCR. Terminals: box lug, 3/8 in hex screw. Mounting: panel. Wire: 500 kcmil-6 AWG Cu/Al, 375 in-lb, solid or stranded. Cover: LT60600FBC cover, one per pole, sold separately. Fits JLLS fuses.
Construction: thermoplastic / laminate, UL94 V-0; zinc-plated steel fuse studs, aluminum box lug contacts.
Approvals: UL Listed, CSA, UL file E14721.
| Category | |
| Manufacturer | LITTELFUSE |
| Model | LFT60 |
| Fuse Type | Class T |
| Holder Type | Class T fuse block |
| Positions | 3 |
| Max Current (A) | 600 |
| Voltage Rating | 600 V |
| Interrupting Rating | 200 kA SCCR |
| Wire Gauge | 500 kcmil-6 AWG Cu/Al, 375 in-lb, solid or stranded |
| Terminal Type | Box lug, 3/8 in hex screw |
| Mounting | Panel |
| Cover | LT60600FBC cover, one per pole, sold separately |
| Housing Material | Thermoplastic / laminate, UL94 V-0 |
| Contact Material | Zinc-plated steel fuse studs, aluminum box lug |
| Fits | JLLS fuses |
| Approvals | UL Listed, CSA |
| UL File Number | E14721 |
