Product Description
Littelfuse Industrial Business Unit L60S Series Fuse; Requires Holder; 4A; 200kA AC, 20kA DC;600 VAC; Fast Blow; Cartridge, Non-Standard
Cylindrical Fuse • Mounting Type: Requires Holder • Fuse Type: Cartridge • Current Rating (Amps): 4A • Voltage Rating - AC: 600 VAC • Response Time: Fast Blow • Breaking Capacity @ Rated Voltage: 200kA AC, 20kA DC • Package / Case: Cartridge, Non-Standard
Product Information
| Manufacturer | Littelfuse Industrial Business Unit |
| Product Category | Fuses |
| Product Sub Category | Cylindrical Fuse |
| Series | L60S Series |
| Catalog Part Number | L60S17.5 |
| Ordering Part Number | L60S17.5T |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 17.5A |
| Voltage Rating - AC | 600 VAC |
| Response Time | Fast Blow |
| Applications | Semiconductors |
| Class | - |
| Approval Agency | CE, CSA, UR |
| Breaking Capacity @ Rated Voltage | 200kA AC, 20kA DC |
| Package / Case | Cartridge, Non-Standard |
| Size / Dimension | 0.811" Dia x 5.000" L (20.60mm x 127.00mm) |
Series Features
L60S/KLC Series TRADITIONAL High-Speed 600 V ac • Very Fast-Acting • 1–800 A
Series DescriptionThe L60S and KLC series is a traditional North American style high-speed fuse for protection of power semiconductor devices that are rated up to 600 V ac. These fuse series are typically used for replacement purposes only. For new designs L70QS series is recommended.
- Compliance with US and Canadian requirements
- Traditional North American cylindrical and bolted style dimensions
- Class aR performance
Small power converters, Power supplies, Control circuits
