Product Description
Littelfuse Industrial Business Unit LF Series Fuse Holder; 30 A;2 Circuit(s); Chassis Mount; 600V; Screw Terminal, Pressure Plate, Quick Connect; 5AG, 13/32" x 1-1/2" (Midget)
Fuse Holder • Mounting Type: Chassis Mount • Fuse Size: 0.394" Dia x 1.496" L (10mm x 38mm) • Current Rating (Amps): 30 A • For Use With/Related Products: 5AG, 13/32" x 1-1/2" (Midget) • Fuse Type: Cartridge • Number of Circuits: 2 • Voltage: 600V • Termination Style: Screw Terminal, Pressure Plate, Quick Connect
Product Information
| Manufacturer | Littelfuse Industrial Business Unit |
| Product Category | Fuses |
| Product Sub Category | Cylindrical Fuse |
| Series | L50QS Series |
| Catalog Part Number | L50QS175 |
| Ordering Part Number | L50QS175.V |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Mounting Type | Bolt Mount |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 175A |
| Voltage Rating - AC | 500 VAC |
| Voltage Rating - DC | 500 VDC |
| Response Time | Fast Blow |
| Applications | Semiconductors |
| Class | - |
| Approval Agency | CE, cURus, UR |
| Breaking Capacity @ Rated Voltage | 200kA AC, 50kA DC |
| Package / Case | Cylindrical, Blade Terminal (Bolt) |
| Size / Dimension | 1.218" Dia x 3.625" L (30.94mm x 92.08mm) |
| Operating Temperature | -55°C ~ 125°C |
Series Features
L50QS SERIES HIGH-SPEED ROUND BODY FUSES 500 Vac/dc • 35-800 A • Traditional Round Body Bolted Style
Series DescriptionThe L50QS Series is a next generation High-Speed Fuse for the protection of power semiconductor devices and is designed in the Traditional North American Bolted Style package.
L50QS Series High-Speed Fuses are extremely current limiting and are used to protect power converters, drives and control circuit applications. Designed with lower I2t performance characteristics, these fuses provide balanced performance to extend longevity while lowering potentially damaging heat energy to the devices being protected.
In addition L50QS Series fuses have been designed with a universal mounting option to meet customer requirements for installation into a variety of application configurations
Littelfuse POWR-SPEED™ products offer optimized circuit protection at the extremely fast speed required to protect modern day, sensitive, high-power semiconductor devices. Such products are commonly found in various industries including pulp and paper industries, cranes and heavy-lifting equipment, processing industries, wastewater treatment plants and large factories and MRO facilities.
- Compliance with US and Canadian Requirements
- Traditional North American Bolted Style dimensions
- Class aR performance
- Direct bus-bar mount or stud mount design
- Halogen Free, RoHS and REACH Compliant
Power Converters (Inverters, Rectifiers), Power Supplies, UPS, Variable Speed Drives, Control Circuits, Soft Starters
